Product Summary

The MSP430F247TPMR is an ultra-low power microcontroller. The device consists of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low-power modes, is optimized to achieve extended battery life in portable measurement applications. The MSP430F247TPMR features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The calibrated digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 1 μs. Typical applications of the MSP430F247TPMR include sensor systems, industrial control applications, hand-held meters, etc.

Parametrics

MSP430F247TPMR absolute maximum ratings: (1)Voltage applied at VCC to VSS: -0.3 V to 4.1 V; (2)Voltage applied to any pin: -0.3 V to VCC + 0.3 V; (3)Diode current at any device terminal: ±2 mA; (4)Storage temperature, Tstg: -55 to 150℃.

Features

MSP430F247TPMR features: (1)Low Supply-Voltage Range, 1.8 V to 3.6 V; (2)Ultra-Low Power Consumption: Active Mode: 270 μA at 1 MHz, 2.2 V; Standby Mode (VLO): 0.3 μA; Off Mode (RAM Retention): 0.1 μA; (3)Ultra-Fast Wake-Up From Standby Mode in Less Than 1 μs; (4)16-Bit RISC Architecture, 62.5-ns Instruction Cycle Time; (5)On-Chip Comparator; (6)Supply Voltage Supervisor/Monitor With Programmable Level Detection; (7)Brownout Detector; (8)Bootstrap Loader; (9)Serial Onboard Programming, No External Programming Voltage Needed, Programmable Code Protection by Security Fuse.
