CS5525-ASZ

Product Summary

The CS5525-ASZ is a highly integrated A/D converter which includes an instrumentation amplifier, a PGA (programmable gain amplifier), eight digital filters, and self and system calibration circuitry. The converters are designed to provide their own negative supply which enables their on-chip instrumentation amplifiers to measure bipolar ground-referenced signals ≤±100 mV. By directly supplying NBV with -2.5 V and with VA+ at 5 V, ±2.5 V signals (with respect to ground) can be measured. The digital filters provide programmable output update rates between 3.76 Hz to 202 Hz (XIN = 32.768 kHz). Output word rates can be increased by approximately 3X by using XIN = 100 kHz. Each filter is designed to settle to full accuracy for its output update rate in one conversion cycle. The filters with word rates of 15 Hz or less (XIN = 32.768 kHz) reject both 50 and 60 Hz (±3 Hz) line interference simultaneously. Low power, single conversion settling time, programmable output rates, and the ability to handle negative input signals make the CS5525-ASZ ideal solutions for isolated and non-isolated applications.

Parametrics

CS5525-ASZ absolute maximum ratings: (1)DC Power Supplies-Positive Digital, Positive Analog: -0.3 +6.0V; (2)Negative Bias Voltage(Negative Potential): +0.3 -3.0 V; (3)Input Current, Any Pin Except Supplies: ±10 mA; (4)Output Current: ±25 mA; (5)Power Dissipation: 500 mW; (6)Digital Input Voltage: -0.3~(VD+)+0.3 V; (7)Ambient Operating Temperature: -40~85℃; (8)Storage Temperature: -65~150℃.

Features

CS5525-ASZ features: (1)Delta-Sigma A/D Converter: Linearity Error-0.0015%FS, Noise Free Resolution-18-bits; (2)Bipolar/Unipolar Input Ranges: 25 mV, 55 mV, 100 mV, 1 V, 2.5 V and 5 V; (3)Chopper Stabilized Instrumentation Amplifier; (4)On-Chip Charge Pump Drive Circuitry; (5)4-Bit Output Latch; (6)Simple three-wire serial interface; (7)Programmable Output Word Rates: 3.76 Hz to 202Hz (XIN = 32.768 kHz), 11.47 Hz to 616 Hz (XIN = 100 kHz); (8)Output Settles in One Conversion Cycle; (9)Simultaneous 50/60 Hz Noise Rejection; (10)System and Self-Calibration with Read/Write Registers; (11)Single +5 V Analog Supply: +3.0 V or +5 V Digital Supply; (12)Low Power Mode Consumption: 4.9 mW.

Diagrams

<IMG alt=" CS5525-ASZ circuit" src="http://www.seekic.com/uploadfile/ic-mfg/2012101202841344.jpg" border=0>
